The Truth 22" Mechanicsville and Hollywood Titanium Street frames are most advanced BMX street frame ever produced. All was made possible by using the latest and best manufacturing equipment and materials available. Frames are hand man made from premium 3Al/2.5V aerospace grade titanium tubing set.
Titanium is half the weight of steel for a tube of the same tensile strength and twice as strong as aluminum alloy. Titanium is also more resistant to fatigue and impact than aluminum alloys. Titanium doesn’t corrode, unlike steel.
Frame use standard 1-1/8" headtube
Full CNC 10mm or 14mm dropouts reduces weigh and increase strength.
CNC Headtube and Bottom bracket
Laser-etched frame graphics
Each frame is hand welded once completed the frame is off to be heat treated. Once the process is completed frames are checked for alignment and if any adjustment is needed it is done now. After we know frame is 100% straight then it is heat treated to T-6 hardness. Our BB shell is machined after final heat-treating process to ensure a smooth installing of bottom bracket.
Meets or exceeds ENBMX Racing standards.
Specification:
Top Tube Length 21.60" Mechanicsville, 22.11" Hollywood.
Rear End length 14.25" center to center
Head tube Angle. 74.25°
Seat post Angle 71°
BB Height 11.60"
Stand over 9"
To place an order, we ask for a 50% non-refundable deposit on stock specs and a full deposit for custom specs to begin. The remaining balance is due when the order is ready to ship.
Production time currently takes about 60 days, excluding weekends and holidays.
Custom specs available with a $300 upcharge.
Titanium Products are handmade, to order. Lead times are only estimates and are not guaranteed.
